Vivo 1 Non-Invasive Ventilation BiPAP Machine
The vivo 1 is a new generation ventilator designed for personalized and comfortable non-invasive respiratory support for non-dependent patients with chronic breathing insufficiency. The intuitive interface ensures ease of use. A comprehensive set of modes and extensive monitoring capabilities allow for great flexibility, making the ventilator a perfect choice for a variety of patients.
Compact:
- One Platform-Three Models
- lightweight and Compact
- Integrated Humidifier with heated wire circuit.
Connected Ready for breas connected are solutions:
- On-Demand Hi-Resolution breath-by-breath data.
- Seamless communication between colleagues and caregiving team.
- Tailored alerts based on patient needs.
- Breas PC software.
- Review Summary and Detailed data.
- Live-Viewer.
Adaptable
- Wide range of modes.
- Adult and pediatric (>10kg)
- Intuitive interface
- Extensive therapy data
- Suitable for use in hospital and home
- Closer monitoring with breas accessory box
Vivi 1 Technical Specifications
- Settings/ performance
- Ventilation modes: PSV, CPAP, S, S/T
- Device Modes: Home, Clinical
- Inspiratory Pressure: 4-25cm H2O
- EPAP: 2-20cm H2O
- CPAP: 4-20cm H2O
- Breath Rate: 0-40bpm
- Inspiratory Time: 0.3-3s
- Rise Time: 1-9
- Inspiratory Trigger: 1-9
- Expiratory Trigger: 1-9
- Minimum Inspiratory Time: Off, 0.3-3s
- Maximum Inspiratory Time: Off, 0.3-3s
- 1Ramp Up: Off, 10-60 min.
- Ramp Down: Off, 10-60 min.
- Ramp Pressure: 2-20 cm H2O
- Humidifier: Off, level 1-5.
- Heated Wire: Off, Level 1-5
Monitoring
- Displayed Data: Ppeak, EPAP, Leakage, MVe, Vte, Total Rate
- I:E Spont Rate, %Spont, Insp Time, Rise Time, SpO2
Power Supply
- Mains Supply: 100 to 240 V AC.
- External DC: 24 V DC
Main Alarms
- Fixed Alarms: High Pressure Limitation, Power failure, SpO2 Disconnected, SpO1 Artifact, Ambient Pressure Compensation Lost Alarm, Hight Patient Air Temperature, Flow Sensor Failure, Internal Function Failure
- Adjustable Alarms: High Pressure, Low Pressure, High Breath Rate, High MV, Low MV, Rebreathing, Apnea, Disconnection, Alarm Sound Level, High EPAP, Low EPAP, High Spo2, Low SpOz, High Pulse Rate, Low Pulse Rate.
- W x H x D: 166x185x200 mm
- Weight: 1.6kg
- Noise level (at 10cm H2O constant pressure): 27.8dB(A)
Intended Use:
Vivo 1 is intended to provide non-invasive ventilation for patients weighing over 10kg (22lbs) who require long-term support or mechanical ventilation for respiratory impairment, with or without obstructive sleep apnea. Vivo 1 is intended for spontaneously breathing patients.
